Products

Our Advanced Tender Monitoring system is our first product.

We also offer affordable bespoke software and hardware solutions for Superyachts

Tender Monitoring and Tracking System
Now taking orders for April delivery

 We’re excited to introduce Yacht Trace TM01, our advanced tender monitoring system, which has been acknowledged by insurers to allow towing at night and extended distances from shore (working in remote areas), often with lower deductibles. We work alongside many insurers, so please contact us for more information.

Protect during towing/antitheft/complete monitoring

Our system is designed for ease of use, security, and reliability, with several unique features including:

  • Two-way communication – No need to board the tender for setup; everything is controlled from the mothership. This enhances safety and allows the tender unit to be discreetly hidden for anti-theft protection.
  • Custom wireless water level sensors – No splicing into bilge pumps, preserving warranties and adding an extra layer of protection.
  • Proprietary hardware & software – Developed entirely in-house, ensuring full control, ongoing improvements, and worldwide compliance. With bespoke work as an option.
  • Secure RF communications – Designed for global use, including the USA and the Mediterranean.
  • Easy installation & portability – The tender unit fits in a cupboard, and the mothership side is housed in a portable case—no need to modify consoles or bridge panels.
  • Independent of AIS – Simplifies installation and operation.
  • Future battery monitoring add-on – Launching later in the year, seamlessly integrates with the existing system.
  • Retail Price: £6,500 (for a 1-tender system). The Iridium option is available at an additional cost (£985 for the hardware plus a 3 years subscription).
  • Prices exclude shipping (DDU).

EASE OF INSTALL

Wireless sensors

Dedicated RF link from tender to Mothership

No need to set up on tender before starting monitoring

User configuable alarms on key parameters

Anti theft features

 Time to install 2-3 hours (vs. 1.5–2 days for alternative systems, reducing complexity and costs).

PHYSICAL ENVIRONMENT

Bilge Sensor – 80mm x 80mm x 60mm + Bilge Switch

Yacht Bridge Display– 270mm x 246mm x 124mm (Peli® 1200 case)

Yacht Mast Unit– 120mm x 120mm x 70mm

Tender/Chase Hub Unit – 120mm x 120mm x 70mm

Bilge Sensor Weight – 380g

Yacht Bridge Display Weight– 2kg

Yacht Mast Unit – 340g

Tender/Chase Hub Unit 340g

Operating Temperature of Mast and Hub Units -25°C to 75 °C

Operating temperature of Bridge Display 0°C to 40°C

ELECTRICAL POWER

BilgeSensor – 2 x AA batteries

Yacht Bridge Display– 12/24V <250mA

Yacht Mast Unit– 12/24V<100mA

Tender/Chase Hub Unit – 12/24V<250mA

POWER CONNECTIONS

Yacht Bridge Display 230/110V Type C

Mast Unit M12 x 5 IP67

Hub Unit M12 x 5 IP67

COMMUNICATION

Wireless IEEE 802.15.4 communication between sensors and hub unit on tender*

Dedicated RF link between Hub Unit and Mast Unit. 1 nm

> Range < 10nm**

Satellite tracking option

Wi-Fi 802.11 b/g/n communication between Mast Unit and the Bridge Display

YACHT BRIDGE DISPLAY (MOUNTED Peli® 1200 case)

4.3” TFT

Capacitive touch screen.

480 x 272 px

MONITORED/ALARMED PARAMETERS OF TENDER/CHASE BOAT

Distance (relative to mothership)

Bilge Level(s)

Battery Voltage (multiple batteries)

Yaw

Pich

Roll

* Wired version for carbon and aluminum boats

** optimal conditions for 10nm

Our system is developed in line with insurance requirements

Over 100,000 yacht owners worldwide put their trust in Pantaenius. The family-owned company has been a leading provider of yacht insurance for over 50 years.

Their comprehensive, specialist solutions for superyachts include hull insurance, liability insurance / P&I, charter cancellation, and crew welfare, as well as pre-delivery and builder’s risk insurance for new builds and major refits. The Pantaenius Superyacht Clauses provide increased coverage and additional benefits while maintaining the famous clarity and certainty of Pantaenius products.

Their international service network and in-house claims department sets them apart from their competitors and whether you own, manage or plan to purchase a vessel, Pantaenius will be happy to provide you with an individual risk assessment and bespoke insurance packages.

pantaenius yacht trace advanced tender monitoring system

Yacht Trace Towing of Tender Monitoring System is recognised by Pantaenius Yacht Insurance as providing the added protection for towing tenders at night.
